THE BASS 30K
BUILT FOR EXTREME BASS
SPECS & DOWNLOADS
DIMENSIONS
9.37" x 2.79" x 41.10" (238 x 71 x 1044mm)
POWER
30,000 Watts
CONNECTIVITY
1
DOWNLOADS
OPERATION CLASS
D
NUMBER OF CHANNELS
1
MAXIMUM POWER
@ 14.4 VDC - 1 Ohm: 30000 Watts RMS @ 14.4 VDC - 2 Ohms: 17010 Watts RMS
INPUT SENSITIVITY
400mV
SIGNAL TO NOISE RATIO
>90dB
FREQUENCY RESPONSE
8Hz ~ 250Hz (-3dB)
CROSSOVER HIGH PASS (HPF)
8Hz ~ 30Hz (-12dB/8ª) Variable
CROSSOVER LOW PASS (LPF)
60Hz ~ 250Hz (-12dB/8ª) Variable
INPUT IMPEDANCE
22K Ohms
PROTECTION SYSTEM
Output Short / Short on output relative to GND / High and Low Power Supply and Thermal protection
MINIMUM SUPPLY VOLTAGE
9 VDC
MAXIMUM SUPPLY VOLTAGE
17 VDC
CONSUMPTION AT REST
400mA
MAXIMUM MUSIC CONSUMPTION
1156A
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL
2312A
WEIGHT
42.24lb (19,20kg)
EAN
7898556844109
